| 시스템 |
렌즈마운트 |
RF 마운트 |
| 센서 |
35mm풀프레임 CMOS센서 |
| 화소수 |
총화소수：약 2670만 화소, 유효화소수：최대약 1900만 화소 |
| ISO감도 |
160-25600(확장시 100-102400) |
| BASE ISO |
800 / 3200 / 12800 / 자동전환(예：Canon Log 2, Canon Log 3, RAW기록 시) |
| 센서모드 |
풀프레임, Super 35mm Crop, Super 16mm Crop |
| ND필터 |
기계식ND필터(2 / 4 / 6 / 8※ / 10stops※)※ 확장선택 시 |
| 프레임레이트 |
6K 59.94P/50.00P (RAW)
4.3K 59.94P/50.00P(RAW)
4K 59.94P/50.00P (RAW/XF-AVC/XF-HEVC S/XF-AVC S)
2K 59.94P/50.00P (RAW/XF-AVC/XF-HEVC S/XF-AVC S) |
| 감마 |
Canon Log ２, Canon Log 3, Canon 709, BT.709 Wide DR, BT.709 Standard, PQ, HLG |
| 컬러스페이스 |
Cinema Gamut, BT.2020 Gamut, BT.709 Gamut |
| 화이트밸런스 |
Auto, 태양광, 전구, 색온도(2000K～15000K), 세트A/B |
| 다이나믹레인지 |
16 stops |
| AF |
듀얼 픽셀CMOS AF II |
| 기록포맷 |
동영상 |
Cinema RAW Light, XF-AVC, XF-HEVC S, XF-AVC S |
| 사진 |
JPEG |
최대 프레임레이트
*(슬로우＆패스트 등) |
풀프레임 6000x3164/60P
Super35mm Crop 4368x2304/100P,4096x2160/120P
Super16mm Crop 2184x1152/180P |
|
|
| 기록포맷(오디오) |
리니어PCM 24bit/48kHz/4ch |
| AAC 16bit/48kHz/2ch(XF-HEVC S / XF-AVC S) |
| 기록미디어 |
CFexpress카드, SD카드 |
| 액정모니터 |
3.5형 LCD 276만 도트, 터치패널 |
| 뷰파인더 |
No |
| 멀티악세서리슈(21pin) |
Yes(전기접점 O) |
| Wi-Fi |
내장 |
| 입・출력단자 |
LENS |
Yes |
| SDI OUT |
Yes(BNC단자x1, 12G/6G/3G/HD-SDI) |
| MON. |
Yes(BNC단자x1, 3G/HD-SDI) |
| HDMI |
Type-A |
| INPUT |
Mini-XLR x2(AES/EBU 비대응) |
| 이더넷 |
Yes |
| USB |
USB Type-C, 스마트폰접속용 |
| VIDEO |
USB Type-C*1, LCD접속용 |
| GRIP |
USB Type-C*1, 그립접속용 |
| MIC |
Φ3.5mm 스테레오미니잭 |
| 헤드폰 |
Yes(스테레오) |
| REMOTE A(φ2.5mm) |
Yes(REMOTE단자) |
| REMOTE B(RS-422) |
NO |
| TC(TIME CODE) |
Yes(DIN단자) |
| G-LOCK |
Yes(DIN단자)*2 |
| SYNC |
Yes(DIN단자)*2 |
| RET |
Yes(DIN단자)*2 |
| DC-IN 12V |
XLR(4pin) |
| 전원・기타 |
배터리 |
BP-A30N, BP-A60N |
보관온도/동작온도
(성능보증/작동보증) |
성능보증：약 0 ℃～ 40 ℃ 85％(상대습도)
작동보증：약 -5 ℃～ 45 ℃ 60％(상대습도) |
|
| 외형치수(폭×높이×깊이) |
약 142 x 135 x 135mm |
| 본체 무게 |
약 1540 g |
|
포맷 |
Codec |
Intra-frame / Long GOP |
샘플링 |
해상도 |
최대 비트레이트 |
Slow & Fast 모션
최대 프레임레이트 |
|
![図形 中程度の精度で自動的に生成された説明]() |
- |
- |
12bit |
6000x3164 |
2130Mbps (59.94P ST) |
60P |
| 1780Mbps (50.00P ST) |
| 4368x2304 |
2290Mbps (59.94P HQ) |
100P |
| 1910Mbps (50.00P HQ) |
| 4096x2160 |
993Mbps (59.94P ST) |
120P |
| 828Mbps (50.00P ST) |
| 2184x1152 |
574Mbps (59.94P HQ) |
180P |
| 479Mbps (50.00P HQ) |
|
![図形 中程度の精度で自動的に生成された説明]()
|
H.264 /
AVC |
Intra-frame |
422
10bit |
4096 x 2160
3840 x 2160 |
1200Mbps (59.94P)
1000Mbps (50.00P) |
120P |
2048 x 1080
1920 x 1080 |
300Mbps (59.94P)
250Mbps (50.00P) |
180P |
| 1920 x 1080 |
150Mbps (59.94i)
125Mbps (50.00i) |
- |
| Long GOP |
422
10bit |
4096 x 2160 |
250Mbps (59.94P/50.00P) |
120P |
| 3840 x 2160 |
150Mbps (29.97P/25.00P/24.00P/23.98P) |
| 2048 x 1080 |
50Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
| 1920 x 1080 |
50Mbps (59.94i/50.00i) |
- |
420
8bit
(Proxy) |
2048 x 1080 |
35Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
35Mbps (59.94P/59.94i/50.00P/50.00i/29.97P/25.00P/24.00P/23.98P) |
- |
|
![]()
|
H.265 /
HEVC |
Long GOP |
422
10bit |
4096 x 2160 |
225Mbps (59.94P/50.00P) |
120P |
| 3840 x 2160 |
135Mbps (29.97P/25.00P/24.00P/23.98P) |
| 2048 x 1080 |
50Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
420
10bit |
4096 x 2160 |
150Mbps (59.94P/50.00P) |
120P |
| 3840 x 2160 |
100Mbps (29.97P/25.00P/24.00P/23.98P) |
| 2048 x 1080 |
35Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
420
10bit
(Proxy) |
2048 x 1080 |
16Mbps/9Mbps (59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
16Mbps/9Mbps (59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
- |
420
8bit
(Proxy) |
1280 x 720 |
6Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
- |
|
![]()
|
H.264 /
AVC |
Intra-frame |
422
10bit |
4096 x 2160 |
1200Mbps (59.94P) |
120P |
| 3840 x 2160 |
1000Mbps (50.00P) |
| 2048 x 1080 |
300Mbps (59.94P) |
180P |
| 1920 x 1080 |
250Mbps (50.00P) |
| Long GOP |
422
10bit |
4096 x 2160 |
250Mpbs (59.94P/50.00P) |
120P |
| 3840 x 2160 |
150Mbps (29.97P/25.00P/24.00P/23.98P) |
| 2048 x 1080 |
50Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
420
8bit |
4096 x 2160 |
150Mpbs (59.94P/50.00P) |
120P |
| 3840 x 2160 |
100Mbps (29.97P/25.00P/24.00P/23.98P) |
| 2048 x 1080 |
35Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
420
8bit
(Proxy) |
2048 x 1080 |
16Mbps/9Mbps (59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
180P |
| 1920 x 1080 |
16Mbps/9Mbps (59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
- |
| 1280 x 720 |
6Mbps
(59.94P/50.00P/29.97P/25.00P/24.00P/23.98P) |
- |
| ※Super 35mm 모드에서 프레임레이트가 100P를 넘는 경우, 화각이 약 6％ 크롭됩니다. |
|
